RADIO CHIME SET MISTRAL 600

Radio chime set
•Incl. transmitter Mistral SE 03.0-s anthracite) and 250 m range
• Transmitter with batteries

The deluxe radio chime with a huge range. Satisfies the utmost
requirements for functionality and individual design
Functions
• 17 appealing polyphonic melodies (including 2/3 tone,
Westminster, classical, pan pipes, kettledrum, glockenspiel, dog)
• User-friendly selection of melodies and two alternately flashing
super-bright white LEDs. easyTIP system
• Alarm function with DIN emergency call tone for special
situations
• Distance booster: any desired range can be achieved by
linking several transmitter/receiver combinations
•Water-proof combination transmission button (IP54) with
inscribable nameplate and LED transmission indicator
• 20 different paging signals for optimum access control,
max. 20 transmitters can be memorised
• Central paging: several receivers can be controlled from
a single transmitter
• Individual paging: each receiver can be controlled individually
from additional transmitters
• Matrix paging: combined central and individual paging is possible
• Transmitter/Receiver pre-programmed at the factory. Easy
memorising of additional transmitters at the touch of a button.
easyTIP system
• Optical and acoustic LowBatt display for the batteries of the
receiver AND of the transmitter
• 4-stage slide switch for paging signal setting (1-melody/
flashing; 2-melody only; 3-flashing only; 4-mute)
• Individual design via 12 supplied glossy motif covers or your own
"creations" and high-quality acrylic sheet with real glass look
• Acrylic sheet lightly frosted on one side. According to installation,
various effects can be obtained with this (depth of focus)
Installation
• Receiver: can be set up on a surface, hung up or screwed
into place; transmitter: can be screwed into place or hung
up with a clip
• Compatible with almost all intercom and doorbell systems
(page forwarding as standard feature)
• Control unit easily accessible
• A neutral covering cap is enclosed for the transmitter especially
for installation with page forwarding.
Technical data
• Range according to transmitter combination 500 m (with
transmitter PSE 04.0) or 250 m (with transmitter SE 03.0),
transmission frequency 868.35 MHz
•Walls, doors, metal parts etc. may significantly reduce the range!
• Where required, use distance booster through the installation
of further radio sets
• Volume max. 83 dB(A), infinitely adjustable
• Receiver: batteries 4 x 1.5 V (alternatively, model LR14/C or
with supplied adapter model LR6/AA, batteries not included
in scope of delivery) or 8-12 V=/~ (via socket or terminal)
• Transmitter: batteries 2 x 1.5 V (model LR03/AAA, included
in scope of delivery) or 8-12 V= (via terminal)
• Typical battery service life: transmitter: 5-10 years, receiver:
5-10 years (when using model LR14/C batteries, otherwise
approx. 1-2 years)
• Dimensions: receiver: 180 x 140 x 50 mm, transmitter
36 x 100 x 17 mm
